Product Details:
|
| Material: | 100% Virgin Tungsten Carbide | Type: | Machining Services |
|---|---|---|---|
| Size: | OEM Accepted | Application: | For Steel Surface Cuting |
| Product Name: | Milling Tools | Precision: | High Precision |
| High Light: | High Precision Carbide Turning Tools,CVD Coating Carbide Turning Tools |
||
Tungsten-Edge CNC Cutting Tool Precision, Reliability And Durability For All Your CNC Needs
Tungsten Carbide CNC Cutting Tools are one of the most useful and versatile tools available for CNC machining. These tools are made from a combination of tungsten carbide, a strong and resilient material, and a cutting edge. The combination of these two materials results in a tool that can cut and shape a variety of materials with a high degree of accuracy and precision. Tungsten Carbide CNC Cutting Tools are capable of cutting through soft metals and harder materials such as stainless steel and aluminum. They are perfect for machining complex shapes with tight tolerances. The tools are also heat-resistant and can withstand high temperatures, making them ideal for use in high-speed machining. Tungsten Carbide CNC Cutting Tools are an essential component of any CNC machining operation and are a reliable and efficient way to produce high-quality parts and components.
Specifiction
| Product Name | Tungsten Carbide CNC Cutting Tools |
| Brand | Minjiang/HL |
| Model | BNM250-S UTX |
| Coating | PVD/CVD |
| Material | 100% Virgin |
| Grade | MC115/MC118/MC118X/MC335/MC335X |
| Workpiece | Steel/Stainless steel/Alloy steel/Cast iron |
| HRA | HRA 89-93 |
| MOQ | 10 pcs |
Material
According to the different binder contents, cemented carbide can be divided into different grades, such as YG, YT and YW . These grades have different performance characteristics and are suitable for different processing materials and processing conditions.
| Grade | WC(%) | TIC(%) | TaC/NbC(%) | Co(%) | Density(t/m³) | Thermal conductivity(W/m·K) | Hardness(HRA) | Flexural strength(/GPa) |
| YG3X | 97 | - | <0.5 | 3 | 14.9-15.3 | 87.92 | 91.5 | 1.08 |
| YG6X | 93.5 | - | 0.5 | 6 | 14.6-15.0 | 75.55 | 91 | 1.37 |
| YG6 | 94 | - | - | 6 | 14.6-15.0 | 75.55 | 89.75 | 1.42 |
| YG8 | 92 | - | - | 8 | 14.5-14.9 | 75.36 | 89 | 1.47 |
| YG10C | 90 | - | - | 10 | 14.3-14.9 | 75.36 | 88 | 1.72 |
| YT30 | 66 | 30 | - | 4 | 9.3-9.7 | 20.93 | 92.5 | 0.88 |
| YT15 | 79 | 15 | - | 6 |
11.0-11.7 |
33.49 | 91 | 1.13 |
| YT14 | 78 | 14 | - | 8 | 11.2-12.0 | 33.49 | 90.5 | 1.77 |
| YT5 | 85 | 5 | - | 10 | 12.5-13.2 | 62.80 | 89 | 1.37 |
| YG6A | 91 | - | 3 | 6 | 14.6-15.0 | - | 91.5 | 1.37 |
| YG8A | 91 | - | 1 | 8 | 14.5-14.9 | - | 98.5 | 1.47 |
| YW1 | 84 | - | 4 | 8 | 12.8-13.3 | - | 91.5 | 1.18 |
| YW2 | 82 | - | 4 | 8 | 12.6-13.0 | - | 90.5 | 1.32 |
Properties&Application
| Grade | Properties | Application |
| YG3X | Fine particle alloy with good wear resistance and poor impact toughness. | Finishing of cast iron, nonferrous metals, finishing of alloy steel, hardened steel, tungsten and molybdenum materials |
| YG6X | Fine-grained alloy with good wear resistance and impact toughness. | Semi-finishing and finishing of cast iron, chilled cast iron, alloy cast iron, heat-resistant steel and alloy steel. |
| YG6 | Good wear resistance and impact resistance. | Rough and semi-finishing of cast iron, non-ferrous metals and alloys, and non-metals. |
| YG8 | Higher strength, better impact resistance, poor wear resistance. | Rough machining of cast iron, non-ferrous metals and alloys, interrupted cutting is possible |
| YT30 | Good red hardness and wear resistance, but low strength, not impact resistant, prone to welding and grinding cracks. | Finishing of carbon steel and alloy steel during continuous cutting. |
| YT15 | Good wear resistance and red hardness, but poor impact resistance. | Semi-finishing and finishing of carbon steel and alloy steel during continuous cutting. |
| YT14 | Higher strength and impact toughness, but lower wear resistance and red hardness than YT15. | Roughing, semi-finishing and finishing of carbon steel and alloy steel during continuous cutting. |
| YT5 | Good strength and impact toughness, not easy to chip, but poor wear resistance. | Rough machining of carbon steel and alloy steel during continuous cutting, and can be used for continuous cutting. |
| YG6A | Fine-grained alloy with good wear resistance and strength. | Semi-finishing and finishing of hard cast iron, ductile iron, non-ferrous metals and alloys, high manganese steel, alloy steel, and hardened steel. |
| YG8A | Medium-grained alloy with good strength and poor red hardness. | Rough and semi-finishing of hard cast iron, ductile iron, white iron, non-ferrous metals, alloys and stainless steel. |
| YW1 | Good red hardness, wear resistance, impact resistance and versatility. | Semi-finishing and finishing of stainless steel, heat-resistant steel, high manganese steel and other difficult-to-process materials. |
| YW2 | Poor red hardness and wear resistance, but high strength and impact resistance. | Semi-finishing and finishing of stainless steel, heat-resistant steel, high manganese steel and other difficult-to-process materials. |
Application fields
Supply At Source
FAQ
1. Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. Or it is 20-35 days if the goods are not in stock, it is according to quantity.
2. Q: Is the price competitive?
A: Yes, we offer reliable products at good prices.
3. Q: Are the products high quality?
A: Yes. The raw material will be tested before bulk production, and we will check the physical properties, shape, and tolerance for ensuring qualified products before shipping.
