Product Details:
|
| Type: | Machining Services | Material: | 100% Virgin Tungsten Carbide |
|---|---|---|---|
| Size: | OEM Accepted | Application: | Petroleum Machinery |
| Keywords: | Cemented Carbide Nozzle | Properties: | High Hardness |
| High Light: | Precision Applications Tungsten Carbide Nozzles,High Performance Carbide Nozzles,Precision Applications Carbide Nozzles |
||
Tungsten Carbide Nozzles are highly advanced tools designed for a wide range of industrial applications. These nozzles possess exceptional characteristics that set them apart from traditional alternatives. The combination of tungsten carbide and other resilient materials results in a product that is incredibly strong, durable, and resistant to wear, corrosion, and extreme temperatures. This makes Tungsten Carbide Nozzles ideal for demanding industrial environments where reliable performance is crucial. With their exceptional wear resistance, these nozzles offer prolonged service life, reducing downtime and maintenance costs. They exhibit remarkable chemical compatibility, ensuring reliable performance even in corrosive environments. The precision engineering of Tungsten Carbide Nozzles enables efficient and consistent material flow, minimizing clogging and ensuring smooth operations. Their versatility allows for applications in various industries, including oil and gas, manufacturing, electronics, and more.
| Grade | ISO Grade | Chemical Composition | Physical Properties | Applications | |||||||
| WC% | CO% | Density g/cm3(±0.1) | Hardness HRA(±0.5) | TRS Mpa(min) | Grain Size(μ m) | ||||||
| YG6 | K20 | 94 | 6 | 14.85-15.00 | 90.5-92 | 1800 | 1.2-1.6 | Carbide burr. | |||
| YG6X | K15 | 94 | 6 | 14.80-15.00 | 91.7-93 | 1600 | ＜1.0 | High wear resistance and higher, strength. Machining of chilled alloy cast irons and refractory alloy steel or finishing of common cast irons. | |||
| YG8 | K30 | 92 | 8 | 14.62-14.82 | 89.5-91 | 1900 | 1.2-1.6 | Wire drawing die and non-standard structure and mechanical component and valve ball. | |||
| YG9 | K40 | 91 | 9 | 14.40-14.60 | 89-90 | 1850 | 1.2-1.6 | Flow sleeves, bushings, rings. | |||
| YG9C | K40 | 91 | 9 | 14.50-14.90 | 87.5-89 | 1815 | 1.2-1.6 | Nozzles, for the petroleum. | |||
| YG11 | K40 | 89 | 11 | 14.35 | 89 | 3200 | 1.6-2.0 | Nozzle, buttons, hemisphere, drilling teeth for the petroleum industry. | |||
| YG11C | - | 89 | 11 | 14.20-14.40 | 87.5-89 | 2200 | 1.6-2.4 | Inserts for mining and high-pressure nozzles in the petroleum, chemical, and mechanic industries. | |||
| YG13 | - | 87 | 13 | 14.10-14.30 | 87.5-89 | 2500 | 1.6-2.0 | Sleeves and bushings. | |||
| YG13C | - | 87 | 13 | 14.05-14.25 | 85.8-87.3 | 2550 | 2.4-4.0 | Alloy teeth and brazing bits. | |||
Product Features
Types of Nozzles
Source Supplier
Sourcing directly from a tungsten carbide manufacturer offers numerous advantages for businesses. Firstly, it ensures a direct and uninterrupted supply chain, eliminating the need for intermediaries and reducing lead times. By bypassing distributors or wholesalers, businesses can establish a closer relationship with the manufacturer, enabling better communication and understanding of specific requirements. Additionally, sourcing from the manufacturer enables businesses to access a wider range of product options and customization possibilities. Manufacturers can offer a comprehensive selection of tungsten carbide grades, sizes, and configurations, allowing businesses to find the perfect fit for their unique applications. Customization options enable businesses to tailor the product to their specific needs, ensuring optimal performance and efficiency.
FAQ
1. Q: Are you a trading company or manufacturer?
A: We are a manufacturer.
2. Q: Do you provide samples? Is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
3. Q: How long does it take for delivery?
A: Delivery time will depend on the shipping method selected, but typically takes between 4-10 days.
4. Q: What makes Tungsten Carbide Nozzles different from other nozzles?
A: Tungsten Carbide Nozzles stand out due to their exceptional strength, durability, and resistance to wear, corrosion, and extreme temperatures. These properties make them ideal for demanding industrial applications.
